Lockwood 7714DA Series Premium Range Surface Mounted Door Closer
Rack and pinion adjustable power door closer suitable for architectural and commercial applications.
Standards and Compliance:
The Lockwood 7714DA series closer has been successfully tested up to four hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS1905.1:2005, Part: Fire Resistant Door sets.
Note: Hold open option is not approved on any fire door.
Specifications:
Power: EN adjustable 1 to 4.
Back check (BC): Adjustable.
Hold Open: Standard Arm Closer does not have Hold-Open feature. Hold-Open Closer can be set at any angle up to 150° of opening.
Handing: Non-handed. Suitable for left or right hand doors.
Cover: Fully formed metal.
Materials: Extruded aluminium body manufactured from high-performance silicon alloy.
Mechanism: Rack and pinion design.
Mounting: Regular, parallel and over-door mounting.
Valves: Adjustable closing and latching speed valves with overload protection.
Delayed Action: Adjustable.
