Series 60 Single Industrial Pulley Block
Single block with 60mm (2 3/8″) sheave, swivel shackle head and black powder coated 316 stainless steel side plates.
FEATURES:
Load rated
Fully articulated swivel shackle head
Durable, low friction acetal polymer sheave
Head bolt: 5/16″ UNC
SPECIFICATIONS:
B.L. (kg): 2000
M.W.L. (kg): 1000
Max. Rope diameter (mm): 12
Weight (g): 390
Pin Ø (mm): 6
Sheave Material: Acetal
Notes: M.W.L. and B.L. is calculated from uniformly distributed load on shackle; i.e. load applied across the full width of the shackle pin.
MATERIALS:
UV stabiised Acetal sheaves.
Grade 316 stainless steel side plate/cheeks, powder coated black.
Grade 316 stainless steel head and shackle.
