Series 30 Ball Bearing Block, Upright Lead
Lead blocks are a low profile solution for leading halyards or other rig sail controls back to cleats or jammers.
Precision moulded Acetal sheaves running on Acetal or Torlon® ball bearings provide high performance & low friction. The 2-stage ball bearing system provides consistent performance over the full load range.
APPLICATIONS:
Typically used for halyards at the mast base.
MATERIALS:
Acetal ball bearings.
UV stabilised Acetal sheave.
Grade 316 stainless steel load housing.
SPECIFICATIONS:
B.L. (kg): 750
M.W.L. (kg): 300
Max. Rope diameter (mm): 8
Weight (g): 30
Fastener Ø (mm): 5
